Low Noise Screw Air Compressor Robust Design 16m³/Min

Low Noise Screw Air Compressor Robust Design 16m³/Min
Low Noise Screw Air Compressor Robust Design 16m³/Min Low Noise Screw Air Compressor Robust Design 16m³/Min

Large Image :  Low Noise Screw Air Compressor Robust Design 16m³/Min

Product Details:
Place of Origin: CHINA
Brand Name: KINGWAY
Certification: CE,ISO
Model Number: LUY160-17
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: WOODEN CARTON
Delivery Time: 30 Working Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 Units Per Year

Low Noise Screw Air Compressor Robust Design 16m³/Min

Description
Product: Air Compressor Brand Name: Kingway
Engine Model: YC6A240-H301 Engine Brand: YuChai
Compressor Oil Capacity(l): 32 Fuel Capacity(l): 250
Engine Form: Air-to-air Cooling, Water Cooling
High Light:

Low Noise Screw Air Compressor

,

16m3/Min Screw Air Compressor

Portable Screw Air Compressor 16m³/Min

Technical Specification



Strong reliability

▶ Robust design ensures long-term reliability and durability of equipment



Easy maintenance

Openable door design, convenient for daily maintenance work



Stage III emission engine

Compliant with China's third-stage non-road diesel engine exhaust emission standards

The fuel injection system adopts the international advanced high-pressure common rail technology and electronically controlled fuel injection, which has higher effect and more horsepower

Low emission, green, environmentally friendly



Diesel self-sufficiency

Even under 100% full load, continuous operation for more than 8 hours



Low noise

The mobile probability canopy and canopy shell design have strong noise reduction and sound absorption effects



Advanced manufacturing technology for high-profile diesel-driven mobile machines

Asymmetric rotor, streamlined rotating parts, while ensuring high compression efficiency, minimizes wear of rotating parts, and achieves longer service life.



Multiple fuel filters

High efficiency, heavy fuel oil filter + water separator effectively prevents impurities and moisture from entering the engine,extend engine life * Some models come standard



High-efficiency air filtration system

A high-performance, three-stage filtration air filter keeps dust and particulates out of the nose and engine, ensuring the power core operates in a superior environment. The indicator light on the air filter will automatically remind you when the filter element should be replaced, eliminating the main worry of maintenance.

Excellent cooling capacity

The device can work in an ultra-high temperature environment (the maximum allowable ambient temperature is up to 50°C)



Dynamic expert system, dynamic multi-point work

Benefit by the most advanced adjustment and control technology, the flow and pressure of Fidelity mobile machine will change continuously with the drilling depth, the additional volume flow makes the slag blowing faster, the drilling effect is higher, and the comprehensive oil series About 5%-15% lower.



Stepless speed regulation

Fixed controller + inlet valve will stepless regulation the engine speed according to the actual gas demand of the customer to achieve the lowest fuel consumption of the equipment



 Technical Date





General Parameter
Model LUY160-17
Working pressure(bar) 17
Volume flow(m3/min) 16
The noise decibel(sound pressure,7m) 83±3
Fuel capacity(l) 250
Compressor oil capacity(l) 32
Maximum ambient temperature up to 50℃
Gas outlet valve(inch)-quantity x size 1XG3/4 1XG2
Engine
Engine brand YuChai
Engine model YC6A240-H301
Engine type In-line, four-stroke, direct injection
Engine cylinder 6
Engine fuel Diesel
Engine power (KW) 176
Maximum engine speed (rpm) 1950
Engine idle speed (rpm) 1200
Engine form Air-to-air cooling, water cooling
Skid Mounted Shipping Dimensions
Length (mm) 2680
Width (mm) 1660
Height (mm) 1669
Weight (kg) 2350
Dimensions With Running Parts, Drawbar Lowered
Length (mm) 4322
Width (mm) 1950
Height (mm) 2010
Weight (kg) 2550



The Reference Pictures:





                        Low Noise Screw Air Compressor Robust Design 16m³/Min 0
