Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame

Certification
China Qingdao Kingway Industry Co., Ltd. certification
China Qingdao Kingway Industry Co., Ltd. certification
I'm Online Chat Now

Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame

Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame
Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame

Large Image :  Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame

Product Details:
Place of Origin: Jiangsu, China
Brand Name: Kingway Power
Certification: ATEX/DNV/CE
Model Number: EADG20-EX2
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD78000/set
Packaging Details: fcl: wrapped with stretch film ;lcl: packed with wood case
Delivery Time: 5 weeks
Payment Terms: L/C, T/T
Supply Ability: 6000 sets per year

Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame

Description
Warranty: 12 Months/2000 Working Hours Rated Voltage: 110V/220V, 230V/400V
Rated Current: 28.8A Speed: 1500rpm/1800rpm
Hazardous Area: Zone 2 Alternator Brand: With Kingway IP55 Alternator
Lifting Frame: DNVGL 2.7-1 Control Panel: With Deepsea/Smartgen
Options: Automatic Transfer Switch Cooling Method: Cooling Method
High Light:

Zone 2 Explosion Proof Generator Set

,

20KVA Explosion Proof Generator Set

20KVA Atex Zone 2 Explosion Proof Generator Set for Oil and Gas Industry with DNV Lifting Frame



  Rated power  20KVA
  Voltage  400V/440V
  Frequency  50Hz@1500RPM, 60HZ@1800RPM
  Controller  ComAp IL3MRS16BAA
  Engine model  404D-22TG
  Hazardous zone  Zone II
  Certification  Declaration of Conformity
  Genset size  2552*1412*1637mm with Lifting Frame
  Gross weight  3000kg







Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame 0

Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame 1Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame 2Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame 3Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame 4Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame 5Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame 6Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame 7



Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame 8



  Equipment  5-1500KVA Explosion-proof Diesel Engine Genset
  Directive  2014/34/UE-ATEX
  Standard   EN 60079 series / EN 1834 series / EN 1755
  Convert to  Group II Equipment, Category 3G ( Zone 2 II B T3 Gc)

Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame 9Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame 10Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame 11Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame 12Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame 13Atex Zone 2 Explosion Proof Generator Set 20KVA with DNV Lifting Frame 14
