1200KW RS232 RS485 Resistive Load Bank For PC Emergency Use

1200KW RS232 RS485 Resistive Load Bank For PC Emergency Use
1200KW RS232 RS485 Resistive Load Bank For PC Emergency Use 1200KW RS232 RS485 Resistive Load Bank For PC Emergency Use 1200KW RS232 RS485 Resistive Load Bank For PC Emergency Use

Large Image :  1200KW RS232 RS485 Resistive Load Bank For PC Emergency Use

Product Details:
Place of Origin: CHINA
Brand Name: KINGWAY
Certification: CE,ISO,ROHS
Model Number: KLB-1200
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: USD33215-35250USD
Packaging Details: Wooden Carton
Delivery Time: 50 Working Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 4000 UNITS PER YEAR

1200KW RS232 RS485 Resistive Load Bank For PC Emergency Use

Description
Product Name: Kingway Resistive Load Bank Rated Volage: 400V
Frequency: 50HZ Max Load Power: 1200KW
Power Factor: 0.8 Communication Interface: RS232/RS485
High Light:

1200KW RS485 Resistive Load Bank

,

400V 1200KW Resistive Load Bank

,

400V 1200KW high power resistor load bank

1200KW RS232 RS485 Resistive Load Bank For PC Emergency Use 0



Kingway 1200KW Resistive Load Bank for PC emergency use





A load bank is a piece of electrical test equipment used to simulate an electrical load, to test an electric power source without connecting it to its normal operating load. During testing, adjustment, calibration, or verification procedures, a load bank is connected to the output of a power source, such as an electric generator, battery, servo amplifier or photovoltaic system, in place of its usual load.



Kingway load bank are designed for both portable and permanently installed applications and can confidently withstand everyday use in a demanding industrial or rental environment, testing range10-5000KW .



                                                                                             Technical Parameter



                                           AC415-1200kW Automatic Load Bank
Rating Voltage/Frequency 415VAC, 3 phase 4 wire, 50Hz
Rated Load Power Resistive load: 1200kW
Load Step

12,2,5,10,10,20,50,100,200,200,

200,200,200kW, min step load: 1kW

PF(Power Factor) 1
Load Tolerance (each step) ±5%
Load Tolerance(overall) ±3%
Display Precision 0.5 class
Control Power External 415VAC/50Hz, 3 phase 4 wire
Wire Connection

Load power supply input——Copper bar (star coupling)

Control power supply input——Connector-bar

Insulation F
Duty Cycle Continuous
Cooling Type Force air cooling, horizontal air inlet and vertical air outlet
Transportation Hoisting, there are lifting lug on top and castors at the bottom of casing
Casing Color Grey(RAL7035)or as required
Dimension About 2600mm*1400mm*1680mm
Weight About 1500kgs
                                                   Operating Environment Parameter
Workplace Indoor
Ambient Temperature -20℃~+50℃
Relative Humidity ≤95%
Altitude ≤2500 meter
Atmospheric Pressure 86~106kPa
Brands of Main Components
Contactor Schneider
Fuse Miro
PLC Siemens
Data processing software Kingway(self-developed)
Alloy Resistance Kingway(self-developed)
1200KW RS232 RS485 Resistive Load Bank For PC Emergency Use 11200KW RS232 RS485 Resistive Load Bank For PC Emergency Use 21200KW RS232 RS485 Resistive Load Bank For PC Emergency Use 31200KW RS232 RS485 Resistive Load Bank For PC Emergency Use 4
1200KW RS232 RS485 Resistive Load Bank For PC Emergency Use 5
1200KW RS232 RS485 Resistive Load Bank For PC Emergency Use 6
1200KW RS232 RS485 Resistive Load Bank For PC Emergency Use 71200KW RS232 RS485 Resistive Load Bank For PC Emergency Use 8
