150KVA Kingway ATEX Certified Zone 2 Silent Diesel Generator Set Integrated DNV Offshore Lifting Frame

Description
Model: EADG150-EX Prime Power: 150KVA/120KW
Frequency: 50HZ Voltage: 400V
Certificate: 《Declaration Of Conformity》 IP Grade: IP55
Category: 3G Conversion: Zone 2 II 3G IIB T3 Gc
Directive: 2014/34/EU-ATEX Standards: EN 60079 Series / EN 1834 Series / EN 1755
Lifting Frame: DNV Standards 2.7-1 (Integrated Offshore Lifting Frame) Generator IP Grade: IP55
Enclosure Box: IP65 Controller: ComAp Mrs16
Ambient Temp: -25℃~ +60℃ Starting Method: Electric Start, Spring Start, Pneumatic Start,Hydraulic Start
ReaHazardous A: Zone 2 Temperature Standards: T3

                   150KVA Kingway ATEX Certified  Zone 2 Silent Diesel Generator Set Integrated DNV Offshore Lifting Frame 0



       150KVA Kingway ATEX Certified Zone 2 Silent Diesel Generator Set Integrated DNV Offshore Lifting Frame



Kingway ATEX Certified Zone 2 Silent Diesel Generator Set with Integrated DNV Offshore Lifting Frame for applications

in Hazardous Area ( Zone 2 ) ,choose the DNV Standards certificate Integrated 2.7-1 lifting frame producing 150KVA @

0.8 pf, 400VAC, 3 Phase +Neutral, 50HZ Output



Quality & Compliance:



The Kingway Ex product will follow the ATEX standard EN 60079 series and EN 1834 series ,and will give awhich is

signed by the manufacturer according to the ATEX Standard EN 1834-1.





Kingway ATEX Certified Zone 2 Silent Diesel Generator Set Specification
Model EADG150-EX
Prime Power 150KVA / 80KW
Frequency 50HZ
Voltage 400V
Certificate

CE, ROHS,ATEX,BV,DNV

IP Grade IP55
Category 3G
Conversion Zone 2 II 3G IIB T3 Gc
Directive 2014/34/EU-ATEX
Standards EN 60079 series / EN 1834 series / EN 1755
Lifting Frame DNV Standards 2.7-1 (Integrated Offshore Lifting frame)
Generator IP Grade IP55
Enclosure Box IP65
Controller ComAp Mrs16
Ambient temp -25℃~ +60℃
Starting Method Electric Start, Spring Start, Pneumatic Start,Hydraulic Start
