Continuous 160kW Natural Gas Engine 1500rpm for 50Hz Power Plant

Continuous 160kW Natural Gas Engine 1500rpm for 50Hz Power Plant
Continuous 160kW Natural Gas Engine 1500rpm for 50Hz Power Plant Continuous 160kW Natural Gas Engine 1500rpm for 50Hz Power Plant Continuous 160kW Natural Gas Engine 1500rpm for 50Hz Power Plant Continuous 160kW Natural Gas Engine 1500rpm for 50Hz Power Plant Continuous 160kW Natural Gas Engine 1500rpm for 50Hz Power Plant Continuous 160kW Natural Gas Engine 1500rpm for 50Hz Power Plant

Large Image :  Continuous 160kW Natural Gas Engine 1500rpm for 50Hz Power Plant

Product Details:
Place of Origin: China
Brand Name: KINGWAY
Certification: CE, ISO
Model Number: KGC200NS
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: usd17,000.00
Packaging Details: wooden case
Delivery Time: 14 days
Payment Terms: T/T,L/C
Supply Ability: 20 UNITS PER Month

Continuous 160kW Natural Gas Engine 1500rpm for 50Hz Power Plant

Description
Speed: 1500 RPM, 1800 RPM Rated Voltage: 230/400V, 110/220V
Ip Level: IP23 Engine Type: 2 Stroke Air Cooled
Cooling System: Water Cooled Rated Frequency: 50hz
Noise: ≤105 DB(A) @ 1m

Continuous 160kW Natural Gas Engine 1500rpm for 50Hz Power Plant

Gas engines are efficient and eco-friendly power equipment compatible with clean energy like natural gas and liquefied gas. With a power range of 50KW-1000KW, they can replace traditional fuel engines and are widely used in scenarios such as power generation, construction machinery, and distributed energy systems, helping customers reduce costs and achieve green production.​

They have three core advantages: high efficiency and energy savings (fuel utilization increased by 15%-20%), low-carbon and environmental protection (no black smoke, CO₂ emissions reduced by over 30%), and stability and durability (annual failure rate ≤0.5%, service life of 15 years). Customized solutions are provided for different industries—for example, generator sets support 72-hour continuous operation, construction machinery is suitable for field work, and distributed energy systems realize combined "power + heat" supply.​

Technical Specifications

Feature Engine Specifications
Model LYC8.3H-G180
Rated /Standby Power(KW) 170/188
Cylinder Number 6
Type 4-Stroke,In-line
Bore x Stroke (mm) 159x159
Compression ratio 17.3:1
Rated speed (RPM) 1500/1800
Displacement (L) 8.3
Cooling method Closed Water-cooled
Type 4 Stoke, In-Line.
Fuel Natural Gas/Biogas/LPG
Voltage 230V/400V, 110V/220V, As Client's Requirement.
Frequency 50HZ/60HZ

Why Choose Our Power Systems?

  • Tailored Combustion: Custom-engineered cylinder heads and pistons optimized for 1500rpm gas combustion and varied heat values.

  • Gas Cleaning Integration: Pre-engineered desulfurization and filtration systems to maximize the 160kW engine's operating life.

  • High ROI: Highly optimized gas consumption at 160kW output ensures rapid project payback.

  • Full-Lifecycle Support: Comprehensive spare parts logistics and remote technical diagnostics tailored for 50Hz gas power plants.


Primary Applications

  • Environmental: Waste-to-energy power generation using biogas at sewage treatment plants and landfills.

  • Agriculture: Continuous on-site power for large-scale livestock farms utilizing manure-based biogas.

  • Oil & Gas: Flared gas recovery and reliable on-site power for drilling rigs and remote operations.


Frequently Asked Questions (FAQ)

Q1: How do I choose the correct generator for my gas source?

A: Gas composition and pressure are critical. Please provide a gas analysis report (including H2S content), and our engineering team will suggest the optimal model.

Q2: Can the generator operate in extreme temperatures?

A: Yes, we provide custom cooling systems, including specialized radiators or heat exchangers, for operational environments ranging from -40°C to +50°C.

Q3: How often is maintenance required?

A: Maintenance cycles depend on gas quality. We provide a tailored maintenance schedule and digital monitoring tools to track performance and predict service intervals.
